Ultraflex T67 Steering Helm 55hp with Black Bezel X
Product code:
4-T67
Manufacturer SKU:
1A0035809J
For use with outboard engines up to 40kw (55hp), with the exception of EVINRUDE E-TEC 50 for which the use of T85 or T71FC is recommended. Features and Technical Specification:All sta Read more
Description
For use with outboard engines up to 40kw (55hp), with the exception of EVINRUDE E-TEC 50 for which the use of T85 or T71FC is recommended.
Features and Technical Specification:
All stainless steel output end of cable as per ABYC P17 safety standards
Corrosion resistant materials
Standard Friction externally adjustable.
90° Black bezel
Four optional helm positions to facilitate steering cable installation
Lock-to-Lock steering wheel turns: Approx. 2.5
Stroke: 230mm
Maximum allowable steering wheel diameter: 380mm (15")
Minimum steering cable bend radius: 200mm (7.9")
Exceeds EN 29775 safety standards.
| Material | Corrosion resistant material and the cable output ends are all stainless steel |
| Supplied With | Bezel |
| Suitable For | 6124** SC-18 or M58 Cable |
| Steering Wheel Turns | 2.5 Lock to Lock |
| Stroke | 228mm (9") |
| Taper | 3/4" |
| Brand | Ultraflex |
| Application | Outboard Engines upto 55Hp (40kw). 6124** (SC-18 or M58) Cable |
| Model | T67 |
| Angle | Bezel: 90 Degrees |
