BEP Pro-Installer Ez-Mount Battery Switch 400A On/Off
Product code:
8-93550
Manufacturer SKU:
770-EZ
The Pro-Installer EZ Mount battery switches make installation both quick and easy. Upward facing studs on the switch base allow direct access to cable connections. The front actuator knob and facia... Read more
Description
The Pro-Installer EZ Mount battery switches make installation both quick and easy. Upward facing studs on the switch base allow direct access to cable connections. The front actuator knob and facia can then be fitted at any 90 degree rotated position to suit the cable runs in and out of the switch. These switches can also be used with Pro-Installer link bars to create cluster configurations to other Pro-Installer products. 770-EZ switch with On/Off operation and 2 x 10mm (3/8") studs.
Surface mount installation
Connects to other Pro-Installer products using link bars
Stainless steel nuts & washers
Strong UV stabilized fibre reinforced plastics
IP66 rated
Tested to UL1107 Ignition Protection, CE Marked
Specifications
Rating Continuous: 400A DC. Intermittent: 600A DC. Cranking: 1500A DC
Voltage: 48V DC for 12-48V Systems
Dimensions: (LxWxH) 98 x 98 x 93mm (3.85" x 3.85" x 3.62")
| Brand | BEP |
