Blue Sea Fuse Block 3AG 6 Circuit+Ground
Product code:
8-25015
Manufacturer SKU:
5015-BSS
ST GLASS FUSE BLOCKS (Screw Terminal) Clear insulating cover with label recesses for large format labels Cover insulates all conductive parts, satisfying ABYC/USCG requirements & storing... Read more
Description
ST GLASS FUSE BLOCKS (Screw Terminal)
Clear insulating cover with label recesses for large format labels
Cover insulates all conductive parts, satisfying ABYC/USCG requirements & storing spare fuses
Tin-plated copper buses & phosphor bronze fuse clips give full 30 Amp rating per circuit
Uses AGC (fast acting) fuses
| Brand | Blue Sea Systems |
This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
| Specifications | |
| Maximum Voltage | 32V DC |
| Max Amps per circuit | 30 Amps DC |
| Max Amperage block | 100 Amps DC |
| Fuse Type | AGC |
| Fuse Rating | 1/8 to 30A DC |
| Screw Terminal | #8-32 with lockwasher |
