Scout Quick 5 3db VHF Fibreglass Whip Antenna 2.4M (8') with 5M Cable

Scout Quick 5 3db VHF Fibreglass Whip Antenna 2.4M (8') with 5M Cable

Name: Scout Quick 5 3db VHF Fibreglass Whip Antenna 2.4M (8') with 5M Cable
SKU: 6-64039

Product code: 6-64039
Manufacturer SKU: P FANNVHF00039T

Description

The Scout Quick 5 is the brand-new line of ready-to-install QuickFit marine antennas, that do not require the installation of RF connectors, easy to remove and totally waterproof thanks to the Scout original foam injection technology. QuickFit antennas are built with FME type termination, they do not require any specific equipment or tools to make the installation on the boat, either on deck, rail or mast. Installation can be carried out easily as no technical skills are required.

The QUICK 5 antenna is a professional 2.40m (8') VHF antenna with 3 dB gain, specifically designed for long range communication. Built with solid brass and copper elements and extra heavy-duty fiberglass 1.5mm thick. Fully foam injected, ice white coloured with high gloss anti-UV filter to prevent colour deterioration.

Releasing the lock nut makes the antenna easily removable from its mount, which is particularly useful during winter storage or during transport of the vessel. Standard ferrule 1" x 14 threads to fit on every type of mount (PA-30 and PA-31 are suggested).

Great construction and convenience make this antenna a great deal both for leisure and commercial boats.

Electrical length: 1/2 λ

Polarisation: Vertical

Specifications

Gain	3 db
Impedance	50 ohm
Material	Fibreglass Whip
Supplied With	5m RG-58 Cable with FME female connectors, 1" x 1/4 Thread Adaptor & FME Male to PL-259 Male Adaptor
Frequency	156-162MHz
Style	Fibre Glass Antenna
Antenna VSWR	1.5:1
DC Ground	Yes
Frequency Description	156-162MHz
Thread Size	1" x 14
Brand	Scout
Model	Quick 5
Wattage	50W maximum
Length	2.4M (8ft)
Weight	0.83kg
Country of Origin	Italy
Warranty	5 Years
